The 7.50-16 Solid Tire is specifically optimized to meet the unique challenges of AGVs operating in complex industrial environments, blending performance, durability, and adaptability. With an outer diameter of approximately 780mm and a section width of 180mm, it is precision-engineered to fit 16-inch rims, ensuring a secure fit that minimizes vibration during operation. The tire’s high-strength rubber carcass—reinforced with a woven fabric layer—provides the tensile strength needed to handle the dynamic loads of AGVs in automated systems. Compliance with international standards (ISO 9001, CE) and rigorous testing in simulated industrial conditions guarantee consistent quality and safety across diverse applications.
Chemical resistance: Laboratory-tested to resist degradation from mineral oils, hydraulic fluids, and weak alkalis (pH 8-10) for up to 500 hours of continuous exposure, making it suitable for chemical processing plants and automotive assembly lines.
Aging resistance: Formulated with anti-oxidants and thermal stabilizers, the tire retains 90% of its elasticity after 3 years of outdoor exposure, outperforming standard rubber tires in long-term durability.
Low maintenance: Requires no inflation checks, valve replacements, or pressure adjustments—reducing maintenance labor by approximately 2 hours per month per AGV compared to pneumatic tire systems.
Versatile application: Available with smooth tread (for polished floors in electronics cleanrooms) or lug tread (for outdoor asphalt in logistics hubs), ensuring optimal performance across surfaces with friction coefficients ranging from 0.3 to 0.8.
High load capacity: Each tire supports a maximum load of 3000-4000 kg, with a safety factor of 1.5x to accommodate occasional overloads during peak operations.
Automated warehouses: Enabling AGVs to operate in 24/7 automated storage and retrieval systems (AS/RS), handling goods ranging from small parts to large pallets with precision.
Food processing facilities: Suitable for environments requiring frequent cleaning, as its smooth surface resists bacterial growth and is compatible with food-grade sanitizers (e.g., chlorine-based solutions).
Pharmaceutical factories: Meeting strict cleanroom standards (ISO 8 and higher) with its low particle emission design, supporting AGVs in transporting raw materials and finished medications.
Q: What is the maximum speed of the tire when used on AGVs?
A: The maximum safe speed is 20-30 km/h on flat, smooth surfaces. For inclined surfaces (up to 5°), a reduced speed of 10-15 km/h is recommended to maintain stability.
Q: Can the tire be installed by regular personnel?
A: No, installation requires specialized hydraulic equipment and training to ensure proper rim seating. Improper installation can lead to rim slippage, which may cause equipment damage or safety hazards.
Q: Is the tire available in colors other than black?
A: While black is standard (due to carbon black’s UV protection benefits), white or gray tires are available for cleanroom applications, where color-coding helps identify contamination risks. Minimum order quantities apply for custom colors.
Item | Specification |
Tire Model | AGV |
Tire Type | Solid Tire (Non-Pneumatic Tire) |
Outer Diameter (OD) | Approx.300mm |
Section Width (SW) | Approx.55mm |
Load Capacity | Single Tire Load: Approx. 800-1000 kg |
Maximum Speed | Approx. 20-30 km/h (Depends on application and load) |
Tread Pattern | - Smooth Tread: Suitable for smooth surfaces (e.g., indoor use) |
Material | - Carcass: High-strength rubber |
Operating Temperature Range | -20°C to +70°C |
Color | Typically black, customizable upon request |
Installation Method | Requires professional hydraulic press for mounting to ensure tight fit |
Applications | - AGV Robot |
Features | - Wear-resistant, puncture-proof |
Certifications | Complies with ISO 9001, CE, and other international standards |
